SKU: 18009
$199.95
Out of stock
Out of stock
| Weight | 4 kg |
|---|---|
| Dimensions | 30 × 30 × 30 cm |
| Specific Type | Specific Value |
| Type | Starter |
| Power Source | Electric |
| Cross Reference Numbers | 1280004020, 211632073, 12498-63010 |
| Engine Model | LX172, 176, GT242, HD45, 170, 175, 240, 245, GS30, |
| MODEL |
T1460-40, T1560-40, T1460-44, FC400V, FC401V, FC420V
|
| Cross Reference Numbers 2 | AM104559 |
| Cross Reference Numbers 3 | hd45, 170, 175, 240, 245, f510, gs25, gs30, gs45, gt242, |
| Manufacturer Part Number | 21163-2073 |
| MPN | 128000-4020 |
| voltage | 12 |
| Number in Pack | 1 |
| Horsepower | 12HP, 13HP, 14HP |
| Compatible Brand | johndeere, Kawasaki, Kubota |
| Material | steel |
| Compatible Model |
T1460B-40, LX172, LX176, FC400V, FC401V, FC420V, GH410V
|
| Denso | 0-128000-4020-00 |
| John Deere | AM104559 |
| Kawasaki | 21163-2073, 21163-2073A |
| Kubota | 12498 - 63010 |
| Lester | 18009 |
| Description: | Starter |
| OEM(s): | Denso, John Deere, Kawasaki |
| Voltage: | 12 |
| Power: | 0.7kW / 0.94HP |
| Condition: | New |
| Rotation: | CCW |
| Starter Type: | DD |
| Number of Teeth: | 9 |
| Gear OD: | 1.142in / 29mm |
| Mtg Ear 1 Hole: | M8-1.25 Threaded |
| Mtg Ear 2 Hole: | M8-1.25 Threaded |
| Warranty: | 1 Year |
| Notes: | Registry Diameter 70mm Mounting Hole C to C 100mm |
| Weight: | 6.85 lbs / 3.11 kg |
| Make | Model | Engine | Years |
| John Deere | 170 | 14HP | 1989 - 1990 |
| John Deere | 175 | 14HP | 1987 - 1990 |
| John Deere | 240 | 14HP | 1988 - 1992 |
| John Deere | 245 | 14HP | 1993 - 1994 |
| John Deere | F510 | 14HP | 1990 |
| John Deere | GS25 | 12HP | 1997 - 2001 |
| John Deere | GS30 | 13HP | 1997 - 2003 |
| John Deere | GS45 | 14HP | 1997 - 2003 |
| John Deere | GT242 | 14HP | 1993 - 1996 |
| John Deere | HD45 | 14HP | 1997 - 2003 |
| John Deere | LX172 | 14HP | 1991 - 1996 |
| John Deere | LX176 | 1991 | |
| John Deere | LX176 | 14HP | 1991 - 1996 |
| Kawasaki | FC400V | - | |
| Kawasaki | FC401V | - | |
| Kawasaki | FC420V | - | |
| Kubota | T1460-40 | GH410V | 1995 |
| Kubota | T1460A-40 | GH410V | 1995 |
| Kubota | T1460B-40 | GH410V | 1995 |
| Kubota | T1560-40 | GH420V | 1995 |
| Kubota | T1560-44 | GH420V | 1995 |
| Kubota | T1560A-40 | GH420V | 1995 |
| Kubota | T1560A-44 | GH420V | 1995 |
| Kubota | T1560B-40 | GH420V | 1995 |
| Kubota | T1560B-44 | GH420V | 1995 |
